Hi every body, last two weeks I was working on understanding what are S7-31x MMCs. In the end I collected following information: 64KB-4MB SIEMENS MMC cards are standard 16MB MMCs with special SIEMENS format. Datasheet at 8MB SIEMENS MMCs are the same but 32MB MMCs. You can make bit copy of these MMCs by using tools at in standard MMC/SD card reader. By using this tools you also copy the special SIEMENS format. But in case you would like to use non SIEMENS 16MB or 32MB MMC, you cant use it in S7 as every MMC has private CID and CSD register where are stored informacion as OEM/APPLICATION ID, PRODUCT NAME. The example of SIEMENS 64KB MMC is at CID is OTP register and first 14 bytes of CSD are programed only by manufacturer.
S7 checks and compares stored info. From CID and CSD.
If you have SIEMENS MMC accidentaly formated in standard MMC/SD card reader/writer (for example as FAT format) you can repair it in this standard MMC/SD reader/writer. Read original SIEMENS MMC by S7imgrd (the same size as failed card) 2.
Write this image to failed MMC by S7imgwr When I was analyzing MMCs I also find out how is the password stored at the MMC. If you have any question, email me at tischer@atlas.cz. Hello, I'm sorry, I have made mistake in description, if you need to make true bit copy of MMC card or you want to repair failed MMC card, you have to use WinHex program (Here is a procedure: a) read the original MMC in 2 steps 1. 64KB image 8MB image b) write the original image into failed MMC 1. Dont you afraid if you receive the following notice 3.!!!! S7imgrd and S7imgwr don't make true bit copy of MMC!!!! Petr tischer@atlas.cz.
You are right, but you can use MMC from other manufacturer if CID and CSD records in the MMC match the SIEMENS CID, CSD records. 64KB-4MB SIEMENS MMC cards work on the same hardware (16MB MMC), 8MB SIEMENS MMC are 32MB MMC. You can't copy format from 4MB card to 64KB as 4MB and 64KB cards work at the same hardware because have diferent CID records. S7s recognise MMC size from CID, CSD and card format. All these three records must match.
CID and CSD records are OTP (one time programable by manufacturer)In CSD register last 8 bits and CRC are partialy user programable. I have made my oven CID and CSD card reader/writer and have programed simple C++ program as I hadn't been able to find any standard MMC reader with posibility to read and write CSD register.
Download video goyang dumang versi upin ipin. Now download videos in all formats from Youtube using GenYoutube video downloader. Using GenYoutube you can download any type of videos from the Youtube. Using it you can search the videos also and can play them too before downloading.
If you still have trouble downloading Siemens simatic s7 200 password unlock mmc 300 hosted on mediafire.com (426 KB), or any other file, post it in comments below and our support team or a community member will help you! If no files were found or matches are not what you expected just use our request file feature.
At the moment I look for any china supplier who will be able supply me with the MMC programed as SIEMENS MMC. If I am succesfull, the price of 8MB MMC will be about 40-50 USD. Images + winhex which there is here do not work. Opera mini 7 download for samsung e2252. I in hopeless position. See With specified above a site (I took an image and filled in it through winhex 14.1 These versions of images were not picked up by the Spanish program. I have overcome a problem by own strength.
The image used 2 mb from the above-stated site. The image has appeared clumsy. It also has helped me.
I have started to compare in 16-HEX a code. It was found out, that sites not deleted on MMC-cards to contain in the end of a file in a range of 00F4C000 addresses - 00F4C0A0. Three bytes being that range should coincide with three bytes in a range 000001C0 - 000001F0. If to be more objective can be and more than 3 bytes, but I think in each of chances it is possible to find dependence. Everyone that has fiddled with this consistently state that you cannot use a regular MMC card as a Siemens MMC card.
